World Class Urodynamic Machine for Reliable Patient Care

Experience precise diagnostic insights
with our trusted Urodynamics System,
delivering accuracy and reliability
worldwide.
Enquire now
About PC Based Urodynamics :
Experience top-tier urological diagnostics with our Santron PC Based Urodynamics System. This advanced tool provides precise measurements, real-time monitoring, and integrates smoothly to enhance patient care. Ideal for evaluating bladder functions, it enables accurate diagnoses and effective treatment planning. Featuring intuitive software, customizable options, and detailed reporting, our system sets a new standard in urological care excellence.

Test which can be performed are: 1. Uroflowmetry
2. Uroflowmetry + EMG
3. Urethral Pressure Profile (UPP)
4. Cystometry + Uroflowmetry
5. Cystometry + Uroflowmetry + EMG
Download catalogue

Specifications:

  • 1. Pressure Sensors : 2 Nos. Measures Vesical Pressure, Abdominal Pressure, Detrusor Pressure, Urethral Pressure.
  • 2. Infused Volume : Volume (Vinf).
  • 3. Infusion Sensor : Weight-based, Maximum 1000 ml plastic bottle can be used.
  • 4. Uroflow : Flow (Qura) and Voided Volume (Qvol).
  • 5. Uroflow sensor: Weight-based Flow Range: 0-100 ml/sec, Sensitivity: 0.5 ml/second.
  • 6. EMG : 1 channel using pad electrodes, Rectified EMG signal.
  • 7. Software : Windows-based, user- friendly software & graphical UI.
  • 8. Connectivity : USB connection to PC.

Watch Product Video

Check out Santron PC based Urodynamics
 System

PRODUCT FEATURES

Hardware Features

Pressure Transducers

  • 1. Reusable, robust, and eliminate the need for costly pressure domes.
  • 2. Ensure precise, highly sensitive measurements with minimal accessory costs.
  • 3. Isolated design prevents wear and damage for long-term use.
  • 4. Compatible with various accessories for seamless integration.

Uroflow Sensor

  • 1. Highly sensitive and precise sensor ensures accurate urinary flow measurements.
  • 2. Offers exceptional accuracy, reliability, and water resistance for optimal performance.

Height Adjustable Sensor Stand

  • 1. Patient can stand and void, without spillage of Urine outside the collection Jar.

Infusion Sensor

  • 1. Provides precise fluid delivery with automatic zero volume adjustment.
  • 2. Alerts for empty bottles to prevent interruptions and errors.
  • 3. Supports versatile infusion rates for pediatric safety.
  • 4. Ensures safe, real-time adjustments and alerts during infusion.

Infusion Pump

  • 1. Automatically starts and stops fluid delivery for efficient testing.
  • 2. Adjustable infusion rates from 0 to 100 ml/min for precise control.
  • 3. Can be controlled via PC software or manual knob for flexibility.
  • 4. Streamlines the infusion process, enhancing focus on patient care.

EMG

  • 1. Single-Channel EMG setup using PAD electrodes.
  • 2. Rectified EMG Signal: Captures & processes muscle activity for real-time analysis.

Software Features

Digital
Calibration

Achieve maximum stability and reliability with digital calibration of all sensors, eliminating the need for analog adjustments.

Intuitive Color
Graphical Interface

Effortlessly navigate bladder sensation events, pump controls, and test functions with a user-friendly button menu, enhancing procedural ease and efficiency.

Auto & Manual
Pressure Channels

Simultaneously and Individual Zero of Pressure Channels Available through Software.

Artifact Removal &
Report Generation

Easily mark multiple graph portions for artifact removal, enhancing data accuracy for calculation and report generation purposes.

Patient Management & Clinical Documentation

Effortlessly store and recall patient studies for ongoing care, with seamless entry of patient history, test conclusions, and reports to support informed decision-making and improve care.

Real-Time Scrolling &
Event Markers

Experience uninterrupted data monitoring with continuous scrolling, allowing flexible insertion, removal, or deletion of event markers as needed during procedures or reviews.

Enhanced Reporting Capabilities

  1. Comprehensive color printouts with detailed test graphs.

  2. Computed parameters and patient details included in all reports.

  3. Standardized reports in the ICS-recommended format with nomograms for precise diagnosis and treatment planning.

  4. Facility to enter patient history, test conclusions, and standard reporting details.

  5. All reports carry hospital and doctors’ information as letterhead.
Request Details

After Sales Service

We’re here to support you long after your purchase

User Training

We provide training services to ensure you and your team can effectively use our devices with proficiency.

Installation Services

Our skilled technical team ensures a smooth installation process, optimizing your device's performance and reliability.

Warranty

Enhance your workflow with our versatile devices, supported by a reassuring 1-year warranty for peace of mind.

Remote Diagnostics

Our remote diagnostic capabilities enables our technicians to identify and resolve issues quickly without onsite visits.

Software Updates

Keep your device at peak performance with regular software updates for the latest features and compatibility.

Standby Services

We provide dedicated support to assist you whenever needed, minimizing disruption to your operations, and maximizing uptime.
